| model |
Z8170ZLC-1 Z8170ZLCZ-1 |
Z8170ZLC-2 Z8170ZLCZ-2 |
Z8170ZLC Z8170ZLCZ |
Z8170ZLC-19 Z8170ZLCZ-19 |
Z8170ZLC-3 Z8170ZLCZ-3 |
Z8170ZLC-4 Z8170ZLCZ-4 |
Z8170ZLC-5 Z8170ZLCZ-5 |
Z8170ZLC-6 Z8170ZLCZ-6 |
Z8170ZLC-18 Z8170ZLCZ-18 |
Z8170ZLC-7 Z8170ZLCZ-7 |
Z8170ZLC-8 Z8170ZLCZ-8 |
Z8170ZLC-9 Z8170ZLCZ-9 |
Z8170ZLC-20 Z8170ZLCZ-20 |
| type |
straight,four-stroke,direction,injection,supercharged,air inter cooling |
| NO.of cylinders |
8 |
| bore/stroke(MM) |
170/200 |
| Rated speed(r/min) |
1000 |
1200 |
1500 |
1350 |
| continuous output(KW) |
300 |
350 |
400 |
440 |
440 |
480 |
350 |
400 |
528 |
540 |
600 |
540 |
575 |
| resolution per hour,power per hour |
1032/330 |
1032/385 |
1032/440 |
1032/484 |
12399/484 |
1239/528 |
1239/385 |
1239/440 |
1239/581 |
1548/594 |
1548/660 |
1394/594 |
1394/633 |
| mean effective pressure(Mpa) |
0.992 |
1.157 |
1.322 |
1.454 |
1.212 |
1.322 |
0.964 |
1.102 |
1.454 |
1.19 |
1.322 |
1.322 |
1.408 |
| mean piston speed(m/s) |
6.67 |
8 |
10 |
9 |
| minimum steady speed under load(r/min) |
400 |
540 |
670 |
600 |
| fuel oil consumption(g/kw.h) |
200 |
| lube oil consumption(g/kw.h) |
1.0 |
| rotation direction of crankshaft |
the left engine resolves right,the right engine resolves right to look from the flywheel side to the free side,to turn right is clockwise |
| the left engine resolves left,the right engine resolvesleft.to look from the flywheel side to the free side,to turn left is counter-clockwise |
| starting method |
air motor,electric motor |
| cooling mode |
closed water cooling |
| lubricating method |
pressure lubricating |
| height of lifting piston from crankshaft(mm) |
1260 |
| overall dimension(mm) |
3080*1400*2050 |
| net weight(kg) |
4300 |
