Product Features:
 1.Adopting three-level technology and efficiency rating of up to 98.1%
 2.Dual input sections with independent MPPT efficiency>99.9%
 3.Electrolyte-free power converter to further increase the life expectancy
 4.High performance index within wide power range
5.Advanced anti-islanding technology
6. Perfect system protection, high reliability
 7.Intergrated DC isolation switch and string combiner(optional)
8. Several communication interfaces, LCD display with several languages
 9.Programmable protective and running parameters
 10.Modular design, easy to install, operate and maintain
 11.Passed rigorous environmental test, suitable for inclement service applications
12.IP65, suitable for outdoor installing

PV side
Max.PV power	3300Wp
Max.permitted DC Voltage	520V
Input short-circuit current	25A
Max.permitted DC current	2*10A
Input points	2
MPPT points	2
MPPT voltage	125 ~ 420 Vdc
PV Start Voltage	150
MPPT voltage range	99.9%
Max Inverter feedback Current to the Array	0A
Grid side
Rated output power	3000Wp
Max.output current	15A
THD of grid current	<3%
Power factor	≥0.99
Max. efficiency	96.9%
European efficiency	96.2%
Output voltage	180 ~ 260 Vac
Permitted grid frequency range	47~51.5Hz
Standby power consumption	5W
Nighttime power consumption	0W
Grid monitoring	According to VDE0126-1-1 guidelines
Communication interface	RS485/Ethernet（optional）/GPRS（optional）
Man-machine interface	LCD
Environmental conditions and safety
Protection level	IP65
Cooling	Natural cooling
Operating temperature range	-25 ~ +60℃
Relative humidity range	0~98%(non condensing)
Mounting altitude	2000m;above 2000m need derate operating
Noise emissions	＜45dB
Meet the standards	IEC 62103; EN 50178;  IEC/EN 62109-1;IEC/EN 62109-2; IEC/EN61000-6-1:2007; IEC/EN61000-6-3:2007;    IEC/EN61000-3-3 :2007; AS/NZS 3100: 2009;   AS4777.2: 2005; AS4777.3: 2005;
Mechanical
Dimensions (W / H / D)	325/535/190(mm)
Weight	18kg
