Product Features:
★Adopting three-level technology and efficiency rating of up to 98.1%
★Dual input sections with independent MPPT efficiency>99.9%
★Electrolyte-free power converter to further increase the life expectancy
★High performance index within wide power range
★Advanced anti-islanding technology
★Perfect system protection, high reliability
★Intergrated DC isolation switch and string combiner(optional)
★Several communication interfaces, LCD display with several languages
★Programmable protective and running parameters
★Modular design, easy to install, operate and maintain
★Passed rigorous environmental test, suitable for inclement service applications
★IP65, suitable for outdoor installing
PV side |
Max.PV power |
2.2kWp |
Max.permitted DC Voltage |
520V |
Input short-circuit current |
16.25A |
Max.permitted DC current |
13A |
Input points |
1 |
MPPT points |
1 |
MPPT voltage |
125 ~ 420 Vdc |
PV Start Voltage |
150Vdc |
MPPT voltage range |
99.9% |
Max Inverter feedback Current to the Array |
0A |
Grid side |
Rated output power |
2kWp |
Max.output current |
10A |
THD of grid current |
<3% |
Power factor |
≥0.99 |
Max. efficiency |
96.5% |
European efficiency |
95.5% |
Output voltage |
180 ~ 260 Vac |
Permitted grid frequency range |
47~51.5Hz |
Standby power consumption |
5W |
Nighttime power consumption |
0W |
Grid monitoring |
According to VDE0126-1-1 guidelines |
communication interface |
RS485/Ethernet(optional)/GPRS(optional) |
Man-machine interface |
LCD |
Environmental conditions and safety |
Protection level |
IP65 |
Cooling |
Natural cooling |
Operating temperature range |
-25 ~ +60℃ |
Relative humidity range |
0~98%(non condensing) |
Mounting altitude |
2000m;above 2000m need derate operating |
Noise emissions |
<45dB@1m |
Meet the standards |
IEC 62103; EN 50178;
IEC/EN 62109-1;IEC/EN 62109-2;
IEC/EN61000-6-1:2007;
IEC/EN61000-6-3:2007;
IEC/EN61000-3-3 :2007;
AS/NZS 3100: 2009;
AS4777.2: 2005; AS4777.3: 2005; |
Mechanical |
Dimensions (W × H × D) |
325/535/190(mm) |
Weight |
14kg |
